    HPH 30KVA I/O=230/400V Delta UPS(No Battery)

    Technical Specifications

    Model
    HPH-30K

    Power Rating
    30 kVA/kW

    Input
    Nominal Voltage: 220/380V, 230/400V, 240/415V (3-phase, 4-wire + G)
    Voltage Range: 305~478 Vac (full load)
    Current Harmonic Distortion: ≤ 2%
    Power Factor: > 0.99
    Frequency Range: 40~70 Hz

    Output
    Voltage: 220/380V, 230/400V, 240/415V (3-phase, 4-wire + G)

    Voltage Harmonic Distortion
    ≤ 1.5% (linear load)
    ≤ 4% (non-linear load)

    Voltage Regulation: ±1% (static)
    Frequency: 50/60 Hz

    Overload Capability
    ≤ 105%: continuously
    > 105 ~ ≤ 110%: 60 minutes
    > 110% ~ ≤ 125%: 10 minutes
    > 125% ~ ≤ 150%: 1 minute
    > 150%: 1 second

    Display: 5” color touch screen

    Interface
    Standard
    External battery temperature dry contact x1, output dry contact x4, Input dry contact x2, Parallel port x2, USB Port x1, RS232 Port x1, REPO Port x1, Mini Slot x2

    Conformance
    Safety: CE, RCM (IEC62040-1, IEC62040-2 Class C2)

    Efficiency
    AC-AC Mode: > 96% (Peak efficiency)
    ECO Mode: 99%

    Battery
    Nominal Voltage: ±240Vdc (default, ±180Vdc~±276Vdc configurable)
    Charge Voltage: ±272Vdc (adjustable from 204V to 312V)
    Maximum Inbuilt Charger Current: 15A
    Discharge Time: 14 minutes
    Environment
    Operating Temperature: 0 ~ 40℃
    Relative Humidity:  0~95% (non-condensing)
    Audible Noise (at one meter) :< 56 dB
    IP Protection: IP20 (Standard)

    Others
    Parallel Redundancy and Expansion: Up to 4 units
    Battery Start: Yes

    Physical
    Dimensions (W x D x H): 240 x 630 x 650 mm

    Weight: 50kg

    Physical (HPH-B/B-N)
    Dimensions (W x D x H): 470 x 780 x 1200 mm

    HPH 30KVA Documents

    User Guide
