Delta RT 5-20kVA 3U EBC 20x9Ah Delta UPS
KSh 138,000.00
In Stock
Have a Question? Ask a us
+254 (0) 111 053-530 Start Whatsapp Chat
Description
New RT 5-20kVA 3U EBC 20x9Ah Delta UPS Technical Specifications
- Model: New RT 5-20kVA 3U EBC
- Power Capacity: 5kVA to 20kVA (5000 VA to 20000 VA) – Scalable
- Form Factor: 3U Rackmount
- Battery Type: Sealed Lead Acid (SLA)
- Battery Capacity: 20x9Ah (20 Batteries of 9Ah Capacity Each)
- Input Voltage: 230V AC (Adjustable)
- Input Frequency: 50/60 Hz (Auto-Sensing)
- Output Voltage: 230V AC (Adjustable)
- Output Frequency: 50/60 Hz (Synchronized with Input)
- Output Waveform: Pure Sine Wave
- Efficiency: ≥ 92%
- Transfer Time: Zero Transfer Time (Online Double Conversion)
- Bypass Voltage: 230V AC (Adjustable)
- Bypass Frequency: 50/60 Hz (Auto-Sensing)
- Overload Capacity: 110% for 60 minutes, 125% for 10 minutes, > 150% for 1 minute
- Crest Factor: 3:1
- Power Factor: ≥ 0.9 (Lagging)
- Communication Ports: RS232, RS485, SNMP, USB (Optional)
- Display: LCD/LED Display for Real-Time UPS Status and Parameters
- Audible Alarm: Battery Mode, Low Battery, Overload, Fault, Bypass Active
- Operating Temperature: 0°C to 40°C (32°F to 104°F)
- Storage Temperature: -15°C to 50°C (5°F to 122°F)
- Humidity: 0% to 95% RH (Non-Condensing)
